King Pellet Stove Manual: An Overview
King pellet stoves offer efficient heating solutions for various spaces, ranging from 1,800 to 3,000 square feet․ Models like the KP5513-W and KP5522-W, alongside the updated KP130, provide warmth and comfort․
King pellet stoves represent a commitment to providing efficient, reliable, and environmentally conscious heating solutions for homes across various climates․ Developed by US Stove Company, these stoves have gained popularity for their ease of use, powerful heating capabilities, and increasingly, their smart home integration features․ The brand caters to diverse heating needs, offering models designed for spaces ranging from smaller rooms to larger, open-concept living areas․
Initially recognized for the classic KP130 model, King has consistently innovated, introducing updated versions and entirely new designs like the KP5513-W and KP5522-W․ These newer models boast enhanced features such as larger hopper capacities – up to 170 lbs – for extended burn times, and Wi-Fi connectivity allowing remote control and monitoring․ The focus remains on delivering consistent warmth and comfort, even in the coldest conditions, while maintaining a sleek and durable design that complements any home décor․
Understanding Pellet Stove Technology
Pellet stoves utilize compressed wood or biomass materials, offering a renewable and efficient heating alternative to traditional wood stoves or fossil fuels․ King pellet stoves employ an auger system to automatically feed pellets from a hopper into a burn pot, where they are ignited․ This controlled combustion process generates heat, which is then circulated throughout the room via a fan – often utilizing a “diverse airflow burner system” for optimal distribution․
A key advantage of pellet stove technology is its efficiency and reduced emissions․ Pellets are denser than firewood, resulting in a longer, more consistent burn․ Modern King models, like the KP5522-W, incorporate features like Wi-Fi connectivity for precise temperature control and monitoring, maximizing efficiency․ The technology also emphasizes safety, with features like automatic shut-off mechanisms and the necessity for proper ventilation to prevent carbon monoxide buildup․

Key Models and Specifications
King offers several pellet stove models, including the KP5513-W (1,800 sq․ ft;), KP5522-W (2,200-3,000 sq․ ft․), and the updated KP130, each with unique features․
King KP5513-W: 1,800 Sq․ Ft․ Model
The King KP5513-W is a modern, compact wood pellet stove designed to efficiently heat spaces up to 1,800 square feet․ A standout feature of this model is its large-capacity, 40-pound pellet hopper, providing up to 30 hours of continuous warmth and comfort on a single fill․ This extended burn time minimizes the need for frequent refueling, enhancing convenience for homeowners․
The stove utilizes an advanced AURORA diverse airflow burner system, ensuring optimal heat distribution throughout the room․ This technology contributes to a consistent and comfortable temperature, even in colder climates․ Its small footprint makes it suitable for various room sizes and layouts, offering a practical heating solution without sacrificing valuable floor space․ The KP5513-W is designed for ease of use and reliable performance, making it a popular choice for those seeking an efficient and convenient heating option․
Hopper Capacity and Burn Time (KP5513-W)
The King KP5513-W boasts a substantial 40-pound capacity pellet hopper, a leading feature in its class․ This generous hopper size directly translates to an impressive burn time, offering homeowners up to 30 hours of continuous, consistent heat on a single loading․ This extended operational period significantly reduces the frequency of refueling, providing enhanced convenience and minimizing user intervention․

The actual burn time can, however, be influenced by several factors, including the heat setting selected, the quality of the pellet fuel used, and the ambient temperature․ Utilizing high-quality, dry pellets will maximize efficiency and burn time․ Regularly monitoring the hopper level is recommended to ensure uninterrupted heating, especially during prolonged periods of cold weather․ The large hopper capacity of the KP5513-W is a key benefit for those seeking a low-maintenance heating solution․
BTU Output and Heating Area (KP5513-W)
The King KP5513-W pellet stove is engineered to efficiently heat spaces up to 1,800 square feet, making it an ideal choice for smaller homes, apartments, or as a supplemental heating source․ While specific BTU output figures can vary, the stove is designed to deliver a robust and consistent heat output suitable for maintaining comfortable temperatures even in colder climates․

The stove’s advanced AURORA diverse airflow burner system contributes to its effective heating performance, ensuring even heat distribution throughout the designated area․ Factors like insulation levels, window efficiency, and ceiling height can influence the actual heating capacity․ It’s recommended to consider these variables when determining if the KP5513-W is the appropriate size for your specific heating needs․ Proper installation and regular maintenance are crucial for maximizing BTU output and ensuring optimal performance․
King KP5522-W: 2,200 ─ 3,000 Sq․ Ft․ Model
The King KP5522-W represents a significant upgrade in heating capacity, designed to comfortably warm larger spaces ranging from 2,200 to 3,000 square feet․ This model builds upon the foundation of the original King stoves, incorporating modern features for enhanced performance and convenience․ A key improvement is the substantially larger 170-pound pellet hopper, providing up to 80 hours of continuous heat without refueling․
Beyond its increased capacity, the KP5522-W distinguishes itself with integrated Wi-Fi connectivity․ This allows users to remotely monitor and control the stove’s settings via a smartphone or other connected device, offering unparalleled convenience and energy management capabilities․ The stove’s durable yet sleek design ensures it blends seamlessly into any home décor while delivering powerful and reliable heat․
Enhanced Hopper Capacity (KP5522-W)
A defining feature of the King KP5522-W is its significantly increased hopper capacity, boasting a substantial 170-pound pellet storage․ This represents a 20% increase compared to previous models, directly translating to extended run times and reduced refueling frequency․ Owners can enjoy up to 80 hours of continuous warmth on a single fill, minimizing the need for constant monitoring and intervention, particularly during extended cold spells or when away from home․
The larger hopper isn’t merely about convenience; it also contributes to a more consistent heating experience․ By holding a greater volume of pellets, the KP5522-W maintains a steadier fuel supply to the burn pot, resulting in more stable temperatures and optimized efficiency․ This enhanced capacity is a core benefit for those seeking a reliable and low-maintenance heating solution․
Wi-Fi Connectivity and Control (KP5522-W)
The King KP5522-W distinguishes itself with integrated Wi-Fi capability, offering users unprecedented control and convenience․ Through a dedicated mobile application, owners can remotely monitor and adjust stove settings from anywhere with an internet connection․ This includes functions like adjusting heat output, initiating startup sequences, and receiving real-time operational status updates․
This remote access proves invaluable for pre-heating a space before arrival, ensuring a comfortable environment upon entering․ Furthermore, the app often provides alerts for low pellet levels or potential operational issues, allowing for proactive maintenance․ The Wi-Fi functionality streamlines operation, enhancing user experience and providing peace of mind․ It’s a modern feature designed for today’s connected lifestyle, maximizing the stove’s usability․
King KP130: Original Model & Updates
The King KP130 represents the foundational model in the King pellet stove lineup, renowned for its durability and reliable performance over the years․ Originally designed to efficiently heat spaces, it has undergone several updates to enhance its functionality and meet evolving standards․ These improvements focus on optimizing combustion efficiency and reducing emissions, ensuring compliance with EPA regulations․
Modern iterations of the KP130 maintain the core design principles of the original while incorporating advancements in burner technology and control systems․ The KP5522-W, for example, is presented as a modern update to the classic KP130, offering increased hopper capacity and Wi-Fi connectivity․ Despite these enhancements, the KP130 remains a popular choice for those seeking a straightforward and dependable heating solution․

Installation and Setup
King pellet stove installation requires proper ventilation, careful consideration of pellet fuel types, and a thorough understanding of the initial startup procedure for safe operation․

Proper Ventilation Requirements
King pellet stoves, while efficient, necessitate strict adherence to proper ventilation guidelines to ensure safe and optimal performance․ These stoves require a dedicated air intake, typically a 4-inch diameter pipe, directly to the outside․ This provides the combustion air needed for efficient burning and prevents negative pressure within the home․
Crucially, the venting system must comply with local building codes and manufacturer specifications․ Improper venting can lead to dangerous carbon monoxide buildup․ The exhaust vent, usually a 3-inch or 4-inch stainless steel pipe, should terminate above the roofline, away from windows and air intakes․
Maintaining adequate clearances around the stove and vent pipes is also vital․ Consult the installation manual for specific distance requirements from combustible materials․ Regular inspection of the venting system for obstructions or damage is essential for continued safe operation․ Failure to follow these guidelines could void the warranty and create a hazardous situation․
Pellet Fuel Considerations
King pellet stoves are designed to operate with high-quality, dry wood pellets that meet the Pellet Fuels Institute (PFI) standards․ Using substandard pellets can lead to inefficient burning, increased creosote buildup, and potential damage to the stove․ Avoid pellets containing excessive fines (dust) or moisture, as these contribute to operational problems․
Premium wood pellets typically offer higher BTU output and cleaner burning characteristics․ Storage of pellet fuel is crucial; keep pellets in a dry, well-ventilated area, protected from rain and snow․ Moisture absorption reduces heating efficiency and can cause clumping, hindering the auger feed system․
Avoid mixing different types of pellets, as variations in composition can affect combustion․ Regularly inspect your pellet supply for signs of deterioration or contamination․ Following these guidelines ensures optimal performance and longevity of your King pellet stove, maximizing heat output and minimizing maintenance․
Initial Startup Procedure
Before the first use of your King pellet stove, ensure the unit is properly installed and vented according to local codes and the installation manual․ Fill the hopper with high-quality, dry wood pellets․ Do not overfill․ Power on the stove and allow the auger to prime – this may take several minutes as pellets are fed from the hopper to the burn pot․
Initiate the startup sequence using the control panel․ The stove will begin a programmed ignition cycle, typically involving a heating element to ignite the pellets․ Monitor the initial burn closely, ensuring proper flame development and airflow․ A small amount of smoke is normal during startup․
Allow the stove to run through several cycles at a low heat setting to fully cure the internal components․ This process helps eliminate any manufacturing residues․ Regularly check the pellet level and ash buildup during the initial burn-in period․ Refer to the troubleshooting section if any issues arise․

Operation and Control

King pellet stoves feature intuitive control panels for adjusting heat output and managing settings․ Newer models, like the KP5522-W, offer convenient Wi-Fi connectivity for remote operation․
Understanding the Control Panel
The King pellet stove control panel is designed for user-friendly operation, allowing precise management of your heating experience․ Typically, you’ll find power buttons for initiating and shutting down the stove, alongside fan speed controls to distribute warmth effectively throughout the room․ Heat output settings are crucial; these often range from low to high, enabling you to customize the temperature based on your comfort preferences and the external weather conditions․
Many models display real-time information, such as hopper levels and internal stove temperatures, providing valuable insights into performance․ The control panel also features settings for adjusting the burn rate, influencing both heat intensity and pellet consumption․ For KP5522-W models, the panel integrates seamlessly with the Wi-Fi functionality, displaying connection status and allowing remote control via a smartphone application․ Error codes, should they appear, are also displayed here, guiding you towards troubleshooting solutions․ Familiarizing yourself with these controls ensures optimal performance and efficient heating․
Adjusting Heat Output Settings
King pellet stoves offer adjustable heat output settings to match your heating needs and conserve fuel․ Typically, the control panel features a range of settings, from a low “smolder” mode for gentle warmth to a high setting for rapid heating․ Experimenting with these settings allows you to find the optimal balance between comfort and efficiency․
Lower settings extend burn times, utilizing less pellet fuel, while higher settings provide more intense heat, ideal for quickly warming a cold space․ Consider the size of the room and the outdoor temperature when selecting a setting․ The KP5513-W and KP5522-W models respond quickly to adjustments, allowing for fine-tuned temperature control․ Remember that increasing the heat output will proportionally increase pellet consumption․ Regularly monitoring the hopper level is recommended when using higher settings․ Utilizing the Wi-Fi functionality on compatible models allows for remote adjustments, ensuring a comfortable temperature upon arrival․
Using the Wi-Fi Functionality
King pellet stoves, specifically the KP5522-W model, boast integrated Wi-Fi connectivity, offering convenient remote control via a dedicated mobile application․ After initial setup – connecting the stove to your home network – you can adjust settings from anywhere with an internet connection․ This includes modifying heat output, monitoring pellet levels, and even initiating or pausing the stove’s operation․
The app provides real-time status updates, alerting you to potential issues like low pellet levels or error codes․ Remote access is particularly useful for pre-heating your home before arrival or adjusting the temperature while away․ Ensure a stable Wi-Fi signal for reliable connectivity․ The app interface is designed for intuitive navigation, allowing for easy control of all stove functions․ Regularly check for app updates to benefit from the latest features and security enhancements․ This feature enhances convenience and optimizes energy usage․

Maintenance and Troubleshooting
King pellet stoves require regular cleaning, including the removal of ash and inspection of the auger․ Addressing error codes promptly, and maintaining the feed system, ensures optimal performance․
Regular Cleaning Procedures
Maintaining your King pellet stove through consistent cleaning is crucial for safe and efficient operation․ Begin by ensuring the stove is completely cool before commencing any cleaning tasks․ Regularly empty the ash pan – frequency depends on usage, but typically every few days to a week is recommended․
Inspect the burn pot and remove any accumulated ash or clinker․ A soft brush is ideal for this, avoiding damage to the components․ The glass door should be cleaned with a specialized pellet stove glass cleaner to remove soot and maintain visibility․
Periodically vacuum the pellet hopper to prevent dust buildup, and check the venting system for obstructions․ A thorough annual inspection by a qualified technician is also advised, including cleaning the flue pipe and checking for proper draft․ Neglecting these procedures can lead to reduced efficiency and potential safety hazards․
Common Error Codes and Solutions
King pellet stoves utilize error codes to diagnose operational issues․ A frequent code, “E1,” often indicates a low hopper level – simply refill the hopper to resolve this․ “E2” typically signals an issue with the auger motor; check for obstructions or a faulty motor․
If you encounter “E3,” it suggests a problem with the exhaust temperature sensor; ensure proper venting and consult a technician if the issue persists․ “E4” usually points to a flame detection error, potentially caused by insufficient pellet flow or a dirty flame sensor․
Consult your specific model’s manual for a complete list of error codes and their corresponding solutions․ Always disconnect power before attempting any repairs․ If you are uncomfortable troubleshooting, contact a qualified service technician to avoid damaging your stove or creating a safety hazard․
Pellet Auger and Feed System Maintenance
King pellet stoves rely on a functional auger and feed system for consistent fuel delivery․ Regularly inspect the auger for wear and tear, replacing it if damaged․ Periodically vacuum the auger tube to remove accumulated dust and debris, ensuring smooth pellet flow․
Check the feed motor for proper operation; listen for unusual noises that might indicate a failing motor․ Inspect the pellet sensor to confirm it’s accurately detecting pellet levels․ A clogged or malfunctioning sensor can disrupt the feed rate․
Before each heating season, thoroughly clean the firepot and burn pot to prevent clumping and ensure efficient combustion․ Always disconnect power before performing any maintenance on the auger or feed system․ Proper maintenance extends the life of your stove and optimizes performance․

Safety Precautions
King pellet stoves require carbon monoxide detectors, proper fuel storage, and knowledge of emergency shutdown procedures․ Prioritize safety to prevent hazards and ensure responsible operation․
Carbon Monoxide Detection
King pellet stoves, while generally safe, produce combustion byproducts, including carbon monoxide (CO)․ This odorless, colorless gas is extremely dangerous and potentially fatal․ Therefore, installing a battery-operated or plug-in carbon monoxide detector is absolutely essential in the same room as the pellet stove, and ideally on every level of your home․
Ensure the detector is UL-listed and regularly tested to confirm its functionality․ Follow the manufacturer’s instructions for placement and maintenance․ Never ignore a CO alarm – if it sounds, immediately evacuate the premises and call emergency services․
Proper stove installation and regular maintenance, including chimney inspections, can minimize CO production․ However, a CO detector remains your primary line of defense against this silent threat․ Prioritize your family’s safety by investing in reliable CO detection․
Proper Fuel Storage
Maintaining the quality of your pellet fuel is crucial for optimal King stove performance and safety․ Store pellets in a dry, well-ventilated area, protected from rain, snow, and direct sunlight․ Moisture absorption can lead to clumping, reduced heating efficiency, and potential operational issues within the stove’s auger and feed system․
Ideally, store pellets indoors, such as in a basement, garage, or dedicated shed․ If outdoor storage is unavoidable, cover the pellet bags tightly with a waterproof tarp, elevating them off the ground to prevent moisture wicking․ Avoid stacking pellets too high, as this can compromise bag integrity․
Use older pellet fuel first to prevent degradation over time․ Regularly inspect stored pellets for signs of moisture or mold․ Proper fuel storage ensures consistent heat output and prolongs the life of your King pellet stove․
Emergency Shutdown Procedures
In the event of an emergency, such as a fire or unusual operating condition, knowing how to quickly and safely shut down your King pellet stove is paramount․ First, immediately disconnect the stove from its power source – unplug it from the electrical outlet․ This halts all electrical functions, including the auger and blower․
Next, if possible without risk, close the fuel shut-off valve․ This prevents further pellets from entering the burn pot․ Allow the stove to completely cool down before attempting any inspection or cleanup․ Do not open the door during or immediately after shutdown, as this can create a draft and potentially spread embers․
Ensure a working carbon monoxide detector is present in the vicinity of the stove․ If you suspect a carbon monoxide leak, evacuate the premises and contact emergency services․ Familiarize yourself with these procedures to ensure a swift and safe response in critical situations․
